Human Machine Interface (HMI) is a device for human to interact with computers through a "touch screen". As long as the industrial control equipment have serial communication capabilities, such as frequency converters, DC speed controllers, temperature controllers or data acquisition modules, can be connected to human-machine interface products to realize the function of human-computer interaction. In addition to supporting traditional serial communication interfaces (RS-232, RS-422, RS-485), human-machine interface products can also communicate with industrial control equipment through ethernet ports, parallel ports, and USB ports.
APPLICATIONS
HMI, Edge Server, IoT Gateway
FEATURES
APPLICATIONS
HMI, Edge Server, IoT Gateway
FEATURES
- CPU: ARM Cortex-A9 Single core, 1 GHz
- NEON: accelerate the encode/decode of audio and video, user interface, 2D/3D graphic
- Memory: DDR3, Flash
- Networking: GbE MAC, GbE PHY
- Interface: CAN, RS485, USB 2.0, SPI/QSPI
- Security: Secure boot, HSE
- Display: LCD controller; size: 1920*1080
